Features:

• Bright Tin Finish
• Nickel-plated Nut Hardware
• 0.010Ω Maximum Contact Resistance
• Keyed Mounting with Double Flats
• Accepts up to 16 Gauge Wire
• Nylon UL approved for self extinguishing

Specifications:

• Type: Banana Jack
• Gender: Female
• Plug/Mating Plug Diameter: Standard Banana
• Mounting Type: Panel Mount
• Termination: Solder Tabs
• Insulation: Mating End Insulated
• Color: Black
• Wire Gauge: 12 AWG
• Contact Finish: Nickel
• Contact Material: Brass
• Operating Temperature: -55°C ~ 85°C
• Contact: Formed brass per QQ-B-626D
• Finish: Bright tin
• Body: Nylon 6/6 per ASTM D4066
• Hardware: Nickel plated nut (unassembled)
• Body Thread Stripping Torque: 6.0 lb. in. (7kg. cm.)
• Panel Thickness: Up to .343 (8.80)

Ratings:

• Current: 15 amps
• Breakdown Voltage: 7000 Vrms minimum
• Contact Resistance: 0.010 ohms maximum
• Contact-To-Panel: 2.4 pF nominal
